Double conductive copper foil tape, embossed copper foil tape, non base conductive double-sided tape.
This product has better shielding effect for electromagnetic ray interference and good performance for grounding electrostatic discharge. At the same time, this product is also used for soldering. Inspection parameters:
Material: Cu 99.98%; base material thickness: 0.018mm-0.05mm; adhesive thickness: 0.035mm; colloidal composition: conductive adhesive (thermal sensitive acrylic adhesive); adhesive force: 1.5-1.3kg/25mm; temperature resistance: - 10 ℃ - 120 ℃; tensile strength: 4.5-4.8kg/mm; elongation: 7-7% - 3-4%.
Note: the product is mainly used to eliminate electromagnetic interference (EMI) and isolate the harm of electromagnetic wave to human body. It is mainly used in the manufacturers of computer peripheral wires, computer monitors and transformers.
1. The test conditions are normal temperature 25 ℃, relative humidity below 65 ℃, and the test results of ASTM-D1000 are adopted.
2. The product is mainly used to eliminate electromagnetic interference (EMI) and isolate the harm of electromagnetic wave to human body. It is mainly used in the manufacturers of computer peripheral wires, computer monitors and transformers.
3. When the goods are stored, please keep the room dry and ventilated, and the storage time is long;
4. It is divided into double-sided conductive and single-sided conductive.
Double conductive copper foil; Base material: copper foil, conductive acrylic adhesive, good adhesion and strong adhesion. Performance: it has the functions of heat preservation, heat insulation, waterproof, good adhesion, good cold resistance, easy tearing, eliminating electromagnetic interference (EMI), isolating the harm of electromagnetic wave to human body, and avoiding the influence of voltage or current. It is mainly used for the production of central air conditioning pipeline, smoking machine, refrigerator, water heater and other pipeline joints, precision electronic products, computer equipment, wires and cables, etc. of computer display, computer peripheral wires and transformers; During high-frequency transmission, it can isolate electromagnetic wave interference, resist high temperature and prevent spontaneous combustion. Specifications: (0.018mm-0.095mm) various thicknesses and widths can be arbitrarily cut.
